| Model Details | |
| Model | FH100 |
| Flow Pattern | Paralle |
| Channel Depth | FH100B 2.6mm / FH100H 4mm |
| Temprature Program ℃ | 5>55>68.5>74>60.5>10.5>4 |
| Plate Material | Stainless/ Ti |
| Plate Thickness mm | 0.5/ 0.6 |
| Gakset Material | NBR/ EPDM |
| Connection Type | DIN, Tri-CLAMP |
| Connection Size | 50 MM |
| Channel Angel | D 120° / X 60° |
| Approval |
UL, CE, ISO9001, ISO14001 |
| Frame Material | Stainless clad |
| Max pressure (bar) | 10 |
| Max Temperature ℃ | 110/140 |
| Min Temperature ℃ | -10 |
| Packing | Polywood Box |
